Technical Specifications:
Material: Solid tungsten carbide
Shank Diameter: ¼" (6.35mm) or 6mm
Cut Type: Single-cut (aluminum, non-ferrous) / Double-cut (steel, iron)
Shapes: Cylinder, ball nose, tree, flame, oval, cone
Operating Speed: Recommended 15,000-30,000 RPM (check material-specific guidelines)
Applications: Metalworking, welding, automotive, aerospace, foundry, woodworking
Why Choose Our Carbide Rotary Files?
Aggressive yet Smooth Cutting: Efficiently removes material without chattering or snagging.
Heat & Wear Resistance: Maintains sharpness even under prolonged use.
Cost-Efficient: Reduced downtime and longer service life lower overall operational costs.
Includes: Single rotary file per order (specify shape/size/cut). Bulk pricing available.
|
Product Name
|
Tungsten Carbide Rotary Burrs
|
|
Material
|
Carbide
|
|
Tooth Types
|
Single Cut/Double Cut
|
|
Sizes
|
Shank dia:3mm,4mm,6mm;blade dia/blade length/overall length: standard/as request
|
|
Applications
|
Using Carbide Rotary Burrs is a effective way to realize mechanization in hand works operations. In the industries of airplane,
ship building automobile, machinery, chemistry etc. Carbide Rotary Burrs can be widely used in machining iron, steel casting, carbon steel, alloy steel, stainless steel, hardened steel, copper, Aluminium etc. |
|
Advantage
|
high productivity, good processing quality, high finish, can be used to process a variety of high economic efficiency.
|
|
Shapes of carbide burrs
|
1.Cylindrical (Plain End)-Shape A;
2.Cylindrical (End Cut)_Shape B; 3.Cylindrical (Radius End)-Shape C; 4.Ball-Shape D; 5.Oval-Shape E; 6.Tree (Radius End)-Shape F; 7.Tree (Pointed Ends)-Shape G; 8.Flame-Shape H; 9. 60°Cone-Shape J; 10.Taper (Radius End)-Shape L;Conical Round Nose-Shape L; 11. Cone -Shape M; 12. 90°Cone-Shape K; 13.Inverted Cone-Shape N; 14.Disc Type with arc edge_Shape W; 15.Disc Type-Shape X; 16.Dics type with 90°Angle-Shape Y |
